220V Watt Flex Cartridge Heaters
Watt flex cartridge heaters Watt-Flex cartridge heaters last up to 5 times longer than conventional heaters with less downtime for heater replacements and lower maintenance costs. Watt-Flex heaters contract when de-energized, eliminating bore seizure and the need for expensive drill-outs....
বিবরণ
Watt flex cartridge heaters
Watt-Flex cartridge heaters last up to 5 times longer than conventional heaters with less downtime for heater replacements and lower maintenance costs. Watt-Flex heaters contract when de-energized, eliminating bore seizure and the need for expensive drill-outs.
|
Material |
stainless steel 304,321,316, Incoloy 800, Incoloy 840, Ti |
|||
|
Insulation |
High-purity Mgo |
|||
|
Resistance Heating Wire |
Ni-Cr or FeCr |
|||
|
Tube Diameter |
3-30mm |
|||
|
Tube Length |
20-5000mm |
|||
|
Voltage Available |
12V/24V/36V/48V/120V/220V/230V/380V |
|||
|
Surface Loading |
1-30w/cm2 |
|||
|
Application |
Used For Injection Molding ,Plastic Molds ,Packaging Equipment |
|||
|
Lead Wire |
300mm length; Different type of wire (Teflon/silicone high temperature frberglass) is available |
|||
Application
Cartidge heater heating rods are suitable for working in heating media that cannot be wired at both ends, such as high and low temperature plug-in heating of various sizes of molds and mechanical equipment, including die and other molds, medical equipment, plastic sealing machines, bottle caps Machine, continuous automatic sealing machine, cigarette making machine, etc.
1. Mold heating has been accepted by a wide range of customers in modern industrial applications.
2. In the plastic mechanical heating system.
3. Pharmaceutical production line.
4. Laboratory heat treatment test.
5. Chemical industry and so on.
